نوع رابط ذخیره سازی
6 *SATA 6Gb/s، 3 *M.2
کارت گرافیک
Integrated Graphics Processor+Intel Thunderbolt 3 Controller
اسلات توسعه
1 *PCI Express x16 slot, running at x16 (PCIEX16)، 1 *PCI Express x16 slot, running at x8 (PCIEX8)، 1 *PCI Express x16 slot, running at x4 (PCIEX4)
RAID
RAID 0, RAID 1, RAID 5, RAID 10
اتصالات
1 *Q-Flash Plus button، 1 *Clear CMOS button، 2 *SMA antenna connectors (2T2R)، 2 *Thunderbolt 3 connectors (USB Type-C ports, with USB 3.2 Gen 2 support)، 4*USB 3.2 Gen 2 Type-A، 2*USB 3.2 Gen 1، 2 *USB 2.0/1.1، 1 *HDMI، 2 *RJ-45، 1 *optical S/PDIF Out connector، 5 *audio jacks
اطلاعات صدا
Realtek ALC1220-VB codec+ESS ES9218P DAC، Realtek ALC1220-VB codec+ESS ES9018K2M DAC+TI OPA1622 operational amplifier
نوع کانکتور ورودی و خروجی
1 *24-pin ATX main power connector، 2 *8-pin ATX 12V power connectors،1 *CPU fan header، 1 *water cooling CPU fan header، 4 *system fan headers، 2 *system fan/water cooling pump headers، 2 *addressable LED strip headers، 2 *RGB LED strip headers، 1 *noise detection header، 1 *front panel header، 1 *front panel audio header، 1 *USB Type-C header, with USB 3.2 Gen 2 support، 1 *USB 3.2 Gen 1 header، 1 *USB 2.0/1.1 header، 2 *temperature sensor headers، 1 *power button، 1 *reset button، 1 *OC button، 2 *BIOS switches
فرم فاکتور
E-ATX
